在 Kubernetes 集群中通过 Rook 部署 ceph 分布式存储集群
https://github.com/rook/rook
Prerequisites:
Kubernetes 1.22+
Helm 3.x
一主三从（最少）
所有 k8s 节点另外准备一块磁盘（裸盘不需要格式化）（/dev/sdb）
1、 rook-ceph-operator
helm repo add rook-release https://charts.rook.io/release
helm repo update
helm search repo rook-release/rook-ceph
helm pull rook-release/rook-ceph --version v1.12.2 --untar
cat > ~/rook-ceph/values-prod.yml << 'EOF'
image:
repository: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph
tag: ceph-v1.12.2
pullPolicy: IfNotPresent
resources:
limits:
cpu: "2"
memory: "4Gi"
requests:
cpu: "1"
memory: "2Gi"
csi:
cephcsi:
# @default -- `quay.io/cephcsi/cephcsi:v3.9.0`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:cephcsi-v3.9.0
registrar:
# @default -- `registry.k8s.io/sig-storage/csi-node-driver-registrar:v2.8.0`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:csi-node-driver-registrar-v2.8.0
provisioner:
# @default -- `registry.k8s.io/sig-storage/csi-provisioner:v3.5.0`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:csi-provisioner-v3.5.0
snapshotter:
# @default -- `registry.k8s.io/sig-storage/csi-snapshotter:v6.2.2`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:csi-snapshotter-v6.2.2
attacher:
# @default -- `registry.k8s.io/sig-storage/csi-attacher:v4.3.0`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:csi-attacher-v4.3.0
resizer:
# @default -- `registry.k8s.io/sig-storage/csi-resizer:v1.8.0`
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:csi-resizer-v1.8.0
# -- Image pull policy
imagePullPolicy: IfNotPresent
EOF
cd ~/rook-ceph
helm upgrade --install --create-namespace --namespace rook-ceph rook-ceph -f ./values-prod.yml .
2、rook-ceph-cluster
helm repo add rook-release https://charts.rook.io/release
helm repo update
helm search repo rook-release/rook-ceph-cluster
helm pull rook-release/rook-ceph-cluster --version v1.12.2 --untar
cat > ~/rook-ceph-cluster/values-prod.yml << 'EOF'
toolbox:
enabled: true
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:ceph-ceph-v17.2.6
cephClusterSpec:
cephVersion:
image: ccr.ccs.tencentyun.com/huanghuanhui/rook-ceph:ceph-ceph-v17.2.6
EOF
cd ~/rook-ceph-cluster
helm upgrade --install --create-namespace --namespace rook-ceph rook-ceph-cluster --set operatorNamespace=rook-ceph -f ./values-prod.yml .
kubectl -n rook-ceph exec -it $(kubectl -n rook-ceph get pod -l "app=rook-ceph-tools" -o jsonpath='{.items[0].metadata.name}') bash
3、NodePort（nodeport方式访问）
kubectl expose pod $(kubectl get pod -n rook-ceph | grep rook-ceph-mgr-a | awk '{print $1}') --type=NodePort --name=rook-ceph-mgr-a-service --port=8443
# kubectl delete service rook-ceph-mgr-a-service
# 访问地址：https://ip+端口
# 密码
kubectl -n rook-ceph get secret rook-ceph-dashboard-password -o jsonpath="{['data']['password']}" | base64 --decode && echo
4、rook-ceph-mgr-dashboard-Ingress（ingress域名方式访问）
cat > ~/rook-ceph/rook-ceph-mgr-dashboard-Ingress.yml << 'EOF'
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: rook-ceph-mgr-dashboard-ingress
namespace: rook-ceph
annotations:
kubernetes.io/ingress.class: "nginx"
kubernetes.io/tls-acme: "true"
nginx.ingress.kubernetes.io/backend-protocol: "HTTPS"
nginx.ingress.kubernetes.io/server-snippet: |
proxy_ssl_verify off;
spec:
rules:
- host: rook-ceph.kevinspace.top
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: rook-ceph-mgr-dashboard
port:
name: https-dashboard
tls:
- hosts:
- rook-ceph.kevinspace.top
secretName: rook-ceph-mgr-dashboard-ingress-tls
EOF
kubectl create secret -n rook-ceph \
tls rook-ceph-mgr-dashboard-ingress-tls \
--key=/root/ssl/kevinspace.top_nginx/kevinspace.top.key \
--cert=/root/ssl/kevinspace.top_nginx/kevinspace.top_bundle.crt
kubectl apply -f ~/rook-ceph/rook-ceph-mgr-dashboard-Ingress.yml
访问地址：rook-ceph.kevinspace.top
用户：admin
密码:
kubectl -n rook-ceph get secret rook-ceph-dashboard-password -o jsonpath="{['data']['password']}" | base64 --decode && echo
helm 安装 rook-ceph 会自动安装3个sc，推荐使用：ceph-block
# https://github.com/rook/rook/issues/12758
ceph crash prune 3 # 保留最近3天的崩溃日志，并删除3天前的以前的日志
ceph crash prune 0
ceph crash ls
[root@master1 ~]# kubectl get pod -n rook-ceph
NAME READY STATUS RESTARTS AGE
csi-cephfsplugin-bkrbr 2/2 Running 0 30m
csi-cephfsplugin-mbwfg 2/2 Running 0 30m
csi-cephfsplugin-provisioner-6cd7f5c469-mfntc 5/5 Running 0 30m
csi-cephfsplugin-provisioner-6cd7f5c469-pg9n2 5/5 Running 0 30m
csi-cephfsplugin-t9gvv 2/2 Running 0 30m
csi-rbdplugin-7t8qj 2/2 Running 0 30m
csi-rbdplugin-82vt7 2/2 Running 0 30m
csi-rbdplugin-provisioner-5f45b9bbc5-24mp9 5/5 Running 0 30m
csi-rbdplugin-provisioner-5f45b9bbc5-z4pk8 5/5 Running 0 30m
csi-rbdplugin-r5bnw 2/2 Running 0 30m
rook-ceph-crashcollector-worker1-6fb86674d4-5vvmx 1/1 Running 0 21m
rook-ceph-crashcollector-worker2-94f8cc64f-shgbw 1/1 Running 0 19m
rook-ceph-crashcollector-worker3-74f5867d74-bm84d 1/1 Running 0 21m
rook-ceph-mds-ceph-filesystem-a-dcb44dcb4-hww6v 2/2 Running 0 21m
rook-ceph-mds-ceph-filesystem-b-6ffd848849-8zjkn 2/2 Running 0 21m
rook-ceph-mgr-a-76975d4759-tlcjx 3/3 Running 0 23m
rook-ceph-mgr-b-66866fbf78-mpcdh 3/3 Running 0 23m
rook-ceph-mon-a-5cd7f8dbb7-t7dks 2/2 Running 0 30m
rook-ceph-mon-b-b6d75d468-l94qj 2/2 Running 0 26m
rook-ceph-mon-c-6d57dc9474-lh5n8 2/2 Running 0 24m
rook-ceph-operator-7c886f57d4-2psbt 1/1 Running 0 35m
rook-ceph-osd-0-59475457f-s7zfc 2/2 Running 0 23m
rook-ceph-osd-1-849c9b9d6-4m62c 2/2 Running 0 22m
rook-ceph-osd-2-5f47d4785f-k6nfw 2/2 Running 0 22m
rook-ceph-osd-prepare-worker1-9zgj4 0/1 Completed 0 20m
rook-ceph-osd-prepare-worker2-74mnx 0/1 Completed 0 20m
rook-ceph-osd-prepare-worker3-x42tv 0/1 Completed 0 20m
rook-ceph-rgw-ceph-objectstore-a-86b9cfc8cb-thqzv 2/2 Running 0 19m
rook-ceph-tools-5469c66bbf-pmmxg 1/1 Running 0 33m
[root@master1 ~]# kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
rook-ceph-mgr ClusterIP 10.111.115.91 <none> 9283/TCP 24m
rook-ceph-mgr-dashboard ClusterIP 10.108.26.167 <none> 8443/TCP 24m
rook-ceph-mon-a ClusterIP 10.105.182.107 <none> 6789/TCP,3300/TCP 31m
rook-ceph-mon-b ClusterIP 10.103.62.93 <none> 6789/TCP,3300/TCP 30m
rook-ceph-mon-c ClusterIP 10.98.148.23 <none> 6789/TCP,3300/TCP 25m
rook-ceph-rgw-ceph-objectstore ClusterIP 10.110.252.234 <none> 80/TCP 22m
[root@master1 ~]# kubectl get sc
NAME PROVISIONER RECLAIMPOLICY VOLUMEBINDINGMODE ALLOWVOLUMEEXPANSION AGE
ceph-block (default) rook-ceph.rbd.csi.ceph.com Delete Immediate true 32m
ceph-bucket rook-ceph.ceph.rook.io/bucket Delete Immediate false 32m
ceph-filesystem rook-ceph.cephfs.csi.ceph.com Delete Immediate true 32m
